Stihl RE 88 User Manual

RE 88
English
22
Specifications
Version: RE 88 RE 88 RE 88 RE 88 RE 88 RE 88
Power supply: 230 V
1~ / 50 Hz
230 - 240 V
1~ / 50 Hz
100 V
1~ / 50 - 60 Hz
120 V
1~ / 60 Hz
127 V
1~ / 60 Hz
220 V
1~ / 60 Hz
Power output: 1.7 kW 1.7 kW 1.3 kW 1.4 kW 1.4 kW 1.7 kW
Fuse (characteristic "C" or
"K"): 10A 10A 15A 15A 15A 10A
Protection class: II II II II II II
Type of protection: IP X5 IP X5 IP X5 IP X5 IP X5 IP X5
Working pressure: 10 MPa
(100 bar)
10 MPa
(100 bar)
6.7 MPa
(67 bar)
7.2 MPa
(72 bar)
7.2 MPa
(72 bar)
10 MPa
(100 bar)
Max. permissible
pressure:
12 MPa
(120 bar)
12 MPa
(120 bar)
10 MPa
(100 bar)
10 MPa
(100 bar)
10 MPa
(100 bar)
12 MPa
(120 bar)
Max. water feed pressure: 1 MPa (10 bar) 1 MPa (10 bar) 1 MPa (10 bar) 1 MPa (10 bar) 1 MPa (10 bar) 1 MPa (10 bar)
Max. water throughput: 520 l/h 520 l/h 450 l/h 460 l/h 470 l/h 520 l/h
Water throughput as per
EN 60335-2-79: 350 l/h 350 l/h 320 l/h 320 l/h 330 l/h 350 l/h
Max. suction lift: 0.5 m 0.5 m 0.5 m 0.5 m 0.5 m 0.5 m
Max. water feed tempera-
ture in the pressurized
water supply: 40 °C 40 °C 40 °C 40 °C 40 °C 40 °C
Max. water feed tempera-
ture in suction operation: 20 °C 20 °C 20 °C 20 °C 20 °C 20 °C
Max. kickback force: 13.7 N 13.7 N 10.4 N 10.8 N 11.2 N 13.7 N
Length approx.: 280 mm 280 mm 280 mm 280 mm 280 mm 280 mm
Width approx.: 250 mm 250 mm 250 mm 250 mm 250 mm 250 mm
Height approx.: 850 mm 850 mm 850 mm 850 mm 850 mm 850 mm
Weight (with spray attach-
ment and high-pressure
hose): approx. 10.4 kg approx. 10.4 kg approx. 9.5 kg approx. 9.5 kg approx. 9.5 kg approx. 10.4 kg
Length of high-pressure
hose (textile braiding): 6 m, DN 06 6 m, DN 06 6 m, DN 06 6 m, DN 06 6 m, DN 066m, DN06

Stihl RE 88 Specifications

General

Brand	Stihl
Model	RE 88
Category	Pressure Washer
Language	English
