13 Operating the Lawn Mower
13.1 Holding and Guiding the Lawn
Mower
► Hold the handlebar with both hands so the
thumbs enclose the handlebar.
13.2 Adjusting the Cutting Height
Six cutting heights can be set:
–
25 mm = position 1
–
30 mm = position 2
–
40 mm = position 3
–
50 mm = position 4
–
60 mm = position 5
–
75 mm = position 6
The positions are indicated on the lawn mower.
► Hold the lawn mower at handle (1).
► Press and hold lever (2).
► Move the lawn mower to the desired position
by raising and lowering the lever.
The current cutting height can be read off at
cutting height indicator (3) by means of mark‐
ing (4).
► Release lever (2).
The lawn mower engages.
13.3 Activating ECO Mode
When ECO mode is activated, the lawn mower
detects the current working conditions and
adjusts the blade speed automatically.
This may extend the battery life.
► Open flap (1) as far as the stop and hold.
► Set ECO switch (2) to the I position.
► Close flap (1).
13.4 Mowing
► Push the lawn mower forwards slowly and in a
controlled manner.
13.5 Emptying the Grass Catcher
Box
The flow of air generated by the blade raises
level indicator (1). The flow of air stops when the
grass catcher box is full. If the flow of air is too
low, level indicator (2) returns to its resting state.
This is a prompt to empty the grass catcher box.
The functionality of the level indicator is restric‐
ted if the flow of air is impaired. External influen‐
English
13 Operating the Lawn Mower
34 0478-131-9946-D
