You’ll need to remove the light
shield in the top of the
refrigerator or freezer to replace
the bulbs. Place your hands under
the light shield and release the
two clips on the back of the light
shield, then lift up and slide back
slowly until the key slots on the
side of the light shield drop past
the mounting studs in the side
walls. Then remove the shield.
The bulbs are now accessible.
Freezer basket lighting is
located below the ice maker
and mounted on the back wall of
the freezer. To remove the light
shield, gently compress the
shield to release the top, then the
bottom. The bulb is now access-
ible. To reinstall the shield, put
the bottom in place first, then
compress and insert the top.
Freezer lighting for Models 611,
611G, 650 and 650G is in the
top of the freezer, mounted to
the front of the evaporator cover.
The bulbs are accessible by
opening the freezer drawer and
unscrewing the bulb from the
top front of the freezer.
Freezer lighting for Models 680
and 690 is accessible above the
ice bucket once the freezer
utility rack has been removed.
See Models 680 & 690 ice
bucket, page 17.
IMPORTANT NOTE: When
the refrigerator or freezer doors
are left open for a long time, the
lights may go off. This protects
the internal parts from
overheating. To reset the light
system, close the door for 15 to
30 minutes.
Your Sub-Zero unit contains
standard 40 watt appliance bulbs
in all compartments.
Like all Sub-Zero units, Models
601RG, 611G and 650G lights
will fully illuminate when the
door is open. With the 601RG,
611G and 650G, however, you
have the option of having
subdued lighting even with the
door closed. You can easily turn
this feature off by depressing the
light ON / OFF key.
23
Lighting
Information
