X11SSH-F/-LN4F User Manual
2.4 Memory Support and Installation
Note: Check the Supermicro website for recommended memory modules.
Important: Exercise extreme care when installing or removing DIMM modules to pre-
vent any possible damage.
Memory Support
The X11SSH-F/-LN4F motherboard supports up to 64GB of unbuffered (UDIMM) DDR4 ECC
2133/1866/1600/1333MHz memory in four memory slots. Populating these DIMM slots with
memory modules of the same type and size will result in interleaved memory, which will
improve memory performance.
DIMM Module Population Conguration
For optimal memory performance, follow the table below when populating memory.
Processors and their Corresponding Memory Modules
CPU# Corresponding DIMM Modules
CPU DIMMA1 DIMMA2 DIMMB1 DIMMB2
Memory Module Population for Optimal Performance
Number of
DIMMs
Memory Population Conguration Table
(For memory to work properly, please follow the instructions below.)
2 DIMMs DIMMB2/DIMMA2
4 DIMMs DIMMB2/DIMMA2, DIMMB1/DIMMA1
Memory Module Population
DIMM Slots
per Channel
DIMM Type
POR Speeds
(MHz)
Ranks per
DIMM
Layer
Count
FW Base
Supported
Voltage
2
Unbuffered
DDR4 ECC
2133,1866,
1600, 1333
SR, DR 6 SPS 1.2V1
Memory Module Population
Max Memory
Possible
4GB DRAM
Technology
8GB DRAM
Technology
Single Rank
UDIMM
16GB
(4x 4GB DIMMs)
32GB
(4x 8GB DIMMs)
Dual Rank
UDIMMs
32GB
(4x 8GB DIMMs)
64GB
(4x 16GB DIMMs)
