LOCATION OF PARTS
TILLER HANDLE MODEL (DF9.9B/15A/20A)
Motor cover
Starter grip
Shift lever
Throttle control grip
Clamp screw
Clamp bracket
Tilt pin
Gear oil level plug
Gear oil drain plug
Anode
Engine oil drain plug
(Reverse side)
Pilot water hole
Flush plug
Water intake hole
Fuel connector
Caution lamp
Combination emergency
stop switch & normal
stop button
Tilt lock lever
Starter button
(Electric starter model)
