Suzuki DF40A User Manual

4
TABLE OF CONTENTS
IDENTIFICATION NUMBER
LOCATION.............................................. 5
FUEL AND OIL....................................... 5
LOCATION OF SAFETY LABELS ..... 8
LOCATION OF PARTS....................... 10
MOTOR MOUNTING.......................... 13
BATTERY INSTALLATION .............. 13
USE OF ELECTRICAL
ACCESSORIES..................................... 15
PROPELLER SELECTION AND
INSTALLATION................................... 15
ADJUSTMENT...................................... 16
INDICATOR.......................................... 22
CAUTION SYSTEM............................. 22
DIAGNOSTIC SYSTEM...................... 26
OIL CHANGE REMINDER
SYSTEM................................................. 26
ENGINE STALLING CAUTION
SYSTEM................................................. 27
OPERATION OF TILTING
SYSTEMS............................................... 28
INSPECTION BEFORE BOATING... 32
BREAK-IN ............................................. 33
OPERATION......................................... 34
MOTOR REMOVAL AND
TRANSPORTING................................. 43
TRAILERING........................................ 45
INSPECTION AND
MAINTENANCE................................... 46
FLUSHING THE WATER
PASSAGES............................................. 55
SUBMERGED MOTOR....................... 57
STORAGE PROCEDURE ................... 58
AFTER STORAGE ............................... 59
TROUBLESHOOTING........................ 59
SPECIFICATIONS ............................... 61
INFORMATION REGARDING
EC – DIRECTIVE................................. 62
CHART OF TOTAL OPERATING
HOURS INDICATION ......................... 62
FLOWCHART OF OIL CHANGE
REMINDER SYSTEM.......................... 64

Suzuki DF40A Specifications

General

Engine Type	4-Stroke
Displacement	941 cc
Max Output	29.4 kW (40 PS)
Full Throttle Operating Range	5000 - 6000 RPM
Steering	Remote
Starting System	Electric
No. of Cylinders	3
Alternator	12V 19A
Engine Mounting	Shear Mount
Trim Method	Power Trim and Tilt
Gear Ratio	2.27:1
Exhaust	Through Prop Hub Exhaust
Cylinders	3
Gear Shift	F-N-R
Shaft Length	L: 508 mm, X: 635 mm
Alternator Output	12V 19A
Fuel System	Sequential Electronic Fuel Injection
Ignition System	Fully transistorized ignition
Oil Pan Capacity	2.7 L
