6-47
INSPECTION AND MAINTENANCE
78RB1-01E
Headlights
LED type
Since special procedures are required, it is
recommended that you take your vehicle
to a SUZUKI dealer for light replacement.
Halogen type
78RB07025
(1) Bulb
78RB07026
1) Open the engine hood while the engine
is stopped. Disconnect the coupler (2).
Remove the sealing rubber (3) by pull-
ing the grip (4).
78RB07027
2) Push the retaining spring (5) forward
and unhook it. Then remove the bulb.
Install a new bulb in the reverse order
of removal.
78RB07028
NOTE:
You can see the position of retaining
spring from the hole of headlight.
