Clutch parts name & part Number
1. 21151-48G00 SPACER, PRIMARY DRIVE GEAR 1
2. 21100-48G00 GEAR ASSY, PRIMARY DRIVE 1
3. 21410-48G00 HUB, CLUTCH 1
4. 21413-48G00 SPRING, CLUTCH 6
5. 21441-48G00 PLATE, CLUTCH DRIVE NO.1
6. 21441-48G10 PLATE, CLUTCH DRIVE NO.2
7. 21441-48G20 PLATE, CLUTCH DRIVE NO.3
8. 21441-48G30 PLATE, CLUTCH DRIVE NO.4
9. 21451-48G00 PLATE, CLUTCH DRIVEN NO.1
10. 21451-48G10 PLATE, CLUTCH DRIVEN NO.2
11. 21462-48G00 DISC, CLUTCH PRESSURE 1
12. 21471-48G00 SEAT, WAVE WASHER 1 109X124X1.6
13. 21472-48G00 WASHER, CLUTCH PLATE 1
14. 21482-41G00 BOLT, CLUTCH SPRING 6
15. 09159-24010 NUT, CLUTCH SLEEVE HUB 1
16. 09160-25056 WASHER, CLUTCH SLEEVE HUB THR 1 25X50X2.50
17. 09160-25056 WASHER, PRIMARY DRIVE 1 25X50X2.50
18. 09164-24006 WASHER, CLUTCH SLEEVE HUB WAV 1
19. 09263-32020 BEARING, PRIMARY DRIVE 1 32X37X38.3
20. 23110-24F00 ROD, CLUTCH 1
21. 23111-48G00 ROD, CLUTCH PUSH, L 1
22. 23121-41G00 PIECE, CLUTCH PUSH 1

Suzuki M109R Specifications

General

Displacement	1783 cc
Bore x Stroke	112.0 mm x 90.5 mm
Compression Ratio	10.5:1
Fuel System	Fuel injection
Ignition	Electronic ignition (transistorized)
Starter	Electric
Transmission	5-speed constant mesh
Final Drive	Shaft drive
Front Suspension	Inverted telescopic, coil spring, oil damped
Rear Suspension	Link type, coil spring, oil damped
Rear Brakes	Single hydraulic disc
Rear Tires	240/40R18M/C 79V, tubeless
Ground Clearance	140 mm (5.5 in)
Seat Height	705 mm (27.8 in)
Engine Type	4-stroke, liquid-cooled, DOHC, V-twin
Front Brakes	Dual hydraulic disc
Front Tires	130/70R18M/C 63H
Overall Length	2, 480 mm
Overall Width	875 mm
Overall Height	1, 130 mm
Wheelbase	1, 710 mm
Curb Weight	347 kg
