General| Displacement | 1783 cc |
|---|---|
| Bore x Stroke | 112.0 mm x 90.5 mm |
| Compression Ratio | 10.5:1 |
| Fuel System | Fuel injection |
| Ignition | Electronic ignition (transistorized) |
| Starter | Electric |
| Transmission | 5-speed constant mesh |
| Final Drive | Shaft drive |
| Front Suspension | Inverted telescopic, coil spring, oil damped |
| Rear Suspension | Link type, coil spring, oil damped |
| Rear Brakes | Single hydraulic disc |
| Rear Tires | 240/40R18M/C 79V, tubeless |
| Ground Clearance | 140 mm (5.5 in) |
| Seat Height | 705 mm (27.8 in) |
| Engine Type | 4-stroke, liquid-cooled, DOHC, V-twin |
| Front Brakes | Dual hydraulic disc |
| Front Tires | 130/70R18M/C 63H |
| Overall Length | 2, 480 mm |
| Overall Width | 875 mm |
| Overall Height | 1, 130 mm |
| Wheelbase | 1, 710 mm |
| Curb Weight | 347 kg |
