REAR SUSPENSION 17-7
• Remove the compression adjuster assembly 1 with the spe-
cial tool from the rear shock absorber.
 09941-53650: Rear shock absorber socket wrench
• Place a drain pan under the rear shock absorber unit.
• Move the rod and drain the oil completely.
• Push the valve core again to equalize the bladder to atmo-
spheric pressure.
• Pour the fresh specified rear suspension oil as shown while
moving the rod.
NOTE:
Be sure to extend the rod after filling the oil.
• Tilt the shock absorber unit as shown and pour the fresh rear
suspension oil fully into the reservoir tank.

99000-99001-S25: SUZUKI REAR SUSPENSION OIL SS-25
 Oil capacity: Approx. 195 ml (6.6/6.9 US/Imp oz)
• Cover the compression adjuster hole by the root of your
thumb.
• Tilt and shake the rear shock absorber unit to fill the reservoir
tank with the oil.
• Add the oil and repeat the above procedure until the reservoir
tank is filled with the oil completely.

Suzuki RM85 Specifications

General

Engine Type	2-stroke, liquid-cooled, single cylinder
Displacement	84.7cc
Bore x Stroke	48.0 mm x 46.8 mm
Ignition	CDI
Transmission	6-speed constant mesh
Final Drive	Chain
Front Brakes	Single hydraulic disc
Rear Brakes	Single hydraulic disc
Compression Ratio	9.5:1
Front Suspension	Inverted telescopic, coil spring, oil damped
Rear Suspension	Swingarm type, coil spring, oil damped
Front Tire	70/100-17
Rear Tire	90/100-14
Overall Width	765 mm
Overall Height	1, 110 mm
Wheelbase	1, 240 mm (48.8 in.)
Curb Weight	73 kg (161 lbs.)
Fuel Tank Capacity	5.5 L
