7-43
Headlight Beam Adjustment
The headlight beam can be
adjusted both horizontally and
vertically if necessary.
To adjust the beam horizontally:
Turn the adjuster 1 clockwise or
counterclockwise.
To adjust the beam vertically:
Turn the adjuster 2 clockwise or
counterclockwise.
NOTE: To adjust the headlight
beam, adjust the beam horizon-
tally first, then adjust vertically.
Turn Signal Light
To replace the turn signal light
bulb, follow these directions.
1. Remove the screw and take off
the lens.
2. Push in on the bulb, turn it to
the left, and pull it out.
CAUTION
Overtightening the screws
when reinstalling the lens may
cause the lens to crack.
Tighten the screws only until
they are snug.
