English
30 Troubleshooting
Removing the microphone
1 Using your thumb or forefinger, lift up one
of the corners of the microphone grommet.
Firmly (but gently) pull that corner until the
seal comes away from the cavity.
2 Repeat to expose an adjacent corner.
3 Pull the exposed corners back and slide the grommet up the
microphone cable to reveal the microphone plug.
4 Remove the plug from the microphone socket.
Reinstalling the microphone
Notice The microphone grommet must be installed whenever
the microphone is plugged into the microphone socket. The
grommet carefully as it serves two important functions. Firstly, it
prevents damage to the microphone socket due to movement
of the microphone cord, and secondly, it ensures that the
control head is sealed against water, dust, and other environ-
mental hazards.
1 Plug the microphone into the microphone socket.
2 Slide the microphone grommet along the microphone cord
and push two adjacent corners of the grommet into the
microphone socket cavity.
3 Squeeze the grommet and push the remaining corners into
position.
4 Check that the grommet is seated correctly in the cavity.
grommet
microphone
grommet
control head
