36
Technical data
Typ 1400 1500 1600
Theoretical performance area operation
width x drive speed (4) x 1000
2750 2750 3500 m2/h
Working width 550 550 700 mm
Squeegee width 850 850 990 mm
Cleaning solution tank / recovery tank 85 85 85 l
Machine speed forward / backwards 5/3 5/3 5/3 km/h
Machine weight / for operation (max.) 151/396 151/396 155/430 kg
Rated voltage 24V 24V 24V dc
Tools 2 x 280 2 x 280 2 x 350 mm
Brush rpm 197 195 152 min-1
Brush pressure 34 31/43 42 kg
Dimensions (L x W x H) 141 x 59 141 x 59 156 x 77 x 100 mm
Rated power 1300 1300 1500 W
Splash water protection IPX3 IPX3 IPX3
Assessed sound level LPA according to
EN 60704-1
<70 <70 <70 dB(A)
The assessed effective acceleration value
according to ISO 5349
0.141 0.141 0.141 m /s2
Electrical protection class III III III
CSD (Cleaning Solution Dosing) yes yes yes
Recycling option yes option
