2.1_ Application limits and dimensions (g. 2)
All performance data of the products in the T-SKY range are pro-
vided in the table “Technical Data” are the only values that enable
and ensure correct evaluation for use.
The structural features of T-SKY products make them suitable for
use on sectional or up-and-over doors, within the limits as speci-
ed in the table.
Model SECTIONAL door
Height Width
T-SKY (guide S-100TSKY080) 2,5m 3,5m
T-SKY (guide
P-100BINBELT3/CHAIN3
) 2,5m 3,5m
T-SKYC (guide S-100TSKY080) 2,5m 3,5m
T-SKYC (guide
P-100BINBELT3/CHAIN3
) 2,5m 3,5m
T-SKY1 (guide S-100TSKY080) 2,5m 5m
T-SKY1 (guide
P-100BINBELT3/CHAIN3
) 2,5m 5m
T-SKYC1 (guide S-100TSKY080) 2,5m 5m
T-SKYC1 (guide
P-100BINBELT3/CHAIN3
) 2,5m 5m
Model UP-AND-OVER
door non projecting
(with accessory
P-150BAN)
Height Width
T-SKY (guide S-100TSKY080) 2,2m 3m
T-SKY (guide
P-100BINBELT3/CHAIN3
) 2,2m 3m
T-SKYC (guide S-100TSKY080) 2,2m 3m
T-SKYC (guide
P-100BINBELT3/CHAIN3
) 2,2m 3m
T-SKY1 (guide S-100TSKY080) 2,2m 4m
T-SKY1 (guide
P-100BINBELT3/CHAIN3
) 2,2m 4m
T-SKYC1 (guide S-100TSKY080) 2,2m 4m
T-SKYC1 (guide
P-100BINBELT3/CHAIN3
) 2,2m 4m
Model UP-AND-OVER
door projecting
(with accessory
P-150BAN)
Height Width
T-SKY (guide S-100TSKY080) 2,8m 3m
T-SKY (guide
P-100BINBELT3/CHAIN3
) 2,8m 3m
T-SKYC (guide S-100TSKY080) 2,8m 3m
T-SKYC (guide
P-100BINBELT3/CHAIN3
) 2,8m 3m
T-SKY1 (guide S-100TSKY080) 2,8m 4m
T-SKY1 (guide
P-100BINBELT3/CHAIN3
) 2,8m 4m
T-SKYC1 (guide S-100TSKY080) 2,8m 4m
T-SKYC1 (guide
P-100BINBELT3/CHAIN3
) 2,8m 4m
Note: if art. P-100PROSKY (or P-100PROSKYC) is used, the
heights stated in the tables may be increased by 1m.
The measurements stated in the tables are guideline only and
serve as a general estimate. The effective suitability of T-SKY for
the automation of a specic door depends on the degree of leaf
balance, friction on the guides and other factors, including occa-
sional events, such as wind pressure or the presence of ice, which
may obstruct leaf movement.
2.2_ Type of system and cable sections (gs. 3-4-5)
1_ Gearmotor with built-in control
2_ Photocells
3_ Photocells on post
4_ Sensitive edge
5_ Flashing light and aerial
6_ Key-operated selector switch
7_ Pushbutton panel
8_ External release (optional)
a_ 4x0,5 mm²
b_ 2x0,5 mm² + RG58
c_ 2x0,5 mm²
d_ 3x0,5 mm²
e_ 3x0,5 mm²
f_ 4x0,5 mm²
3_ INSTALLATION
T-SKY must be installed by qualied personnel in com-
pliance with current legislation, standards and regu-
lations as well as the specications in these instruc-
tions.
3.1_ Preliminary checks
Before installing T-SKY the following checks are required:
• Ensure that all material used is in perfect condition, suitable for
use and compliant with standards.
• Ensure that the door structure is suitable for power-operation.
• Ensure that the door has the force and dimensions within the
application limits as specied in paragraph 2.1.
• Ensure that the door complies with standards EN12604 and
EN12605.
• During movement, the door must never invade public areas
allocated for the transit of pedestrians or vehicles.
• During door travel, ensure that there are no points of marked
friction, both during opening and closing.
• Ensure sufcient strength of the mechanical stops and check
that there is no risk of the door derailing.
• Ensure that the door is adequately balanced, i.e. it should not
move if left stationary in any position.
• Ensure that the xing points of the various devices (photocells,
pushbuttons etc.) are located in areas protected against the
risk of impact, and that the xing surfaces are sufciently sol-
id.
• Ensure that the minimum and maximum clearances are as
specied in gures 6 and 7.
• Ensure that parts of the operator cannot come into contact with
water or other liquids.
• Do not keep T-SKY components near sources of heat or ex-
pose to ames; these actions may damage or cause malfunc-
tions, re or hazardous situations.
• If the door is equipped with a pedestrian pass door, ensure that
this does not obstruct normal door travel; if necessary t a suit-
able interlock system.
• If the door to be automated is up-and-over, check value A of
gure 8, i.e. the minimum distance between the upper edge of
the guide and the maximum point reached by the upper edge
of the door. Otherwise T-SKY cannot be tted.
• Connect the T-SKY power plug to an electrical socket equipped
with safety earthing.
• The electrical socket must be protected by an adequate ther-
mal magnetic cut-out and residual current circuit breaker.
3.2_ Sliding guide assembly
If supplied with the sliding guide in 3 sections, these must be as-
sembled as described below:
1_ Straighten the three tracks after inserting the buttery bracket
on the section (for ceiling mounting), as shown in g. 9.
2_ Slide the joint to join the tracks (g. 10) and secure using the
screw (B g. 10) suppied.
3_ Adjust the tension of the chain/belt by means of the chain ten-
sioner nut (A g. 10) until it is sufciently taut.
Otherwise, if supplied with the pre-assembled guide, tension the
chain/belt until it is sufciently taut.
If the chain/belt is tensioned excessively, the motor will
undergo excessive stress with a consequent increase
in current absorption.
If the height of the door to be power-operated is greater than
2,5 m, the optional accessory 100PROSKY (for chain drive) or
100PROSKYC (for belt drive) is required to extend the sliding
guide by 1 m. To assemble, proceed as follows:
