11 SINGTHING User Manual
10. MIDI
Perhaps you noticed the 5-pin MIDI input on the back panel? If you’re so
inclined, you can control many of your SingThing’s functions using MIDI control
commands (CCs). If this is an entirely new concept to you, don’t worry, it’s pretty
straightforward. Musical Instrument Digital Interface (MIDI) is a standard that
allows cross-platform communication between all kinds of digital instruments.
Part of the MIDI standard is designed to allow controllers (keyboards, buttons,
sliders, knobs, etc) to send messages to devices under control. Some of the CCs
are pre-dened by the MIDI standard, and some are left deliberately open to
allow manufacturers to choose CCs that are specic to certain functions on their
products – SingThing uses both to allow MIDI control over most of its parameters.
The table below shows the MIDI CCs to which SingThing is responsive. If you’d like
to learn more about MIDI CCs, or anything else to do with the MIDI standard, the
good people at TweakHeadz Lab have written one of the best guides we’ve found
so far: http://tweakheadz.com/midi-controllers/
SingThing MIDI Chart
Group Name Instance CC Number
Hit Harmony 21
Hit Delay 22
Hit Reverb 23
Hit Double 24
Hit Correct 25
Hit Sfx 26
Mixer_LW Level Voc_Delay 71
Mixer_LW Level Voc_Reverb 73
Mixer_L_HD Level Doubling 75
Correct Lead_Gender 72
Reverb Decay 91
Mixer_LW Level Voc_uMod 93
Delay FeedbackControl 10
Harmony VibratoBoost 1
Mixer_L_HD Level Harmony 11
Harmony
Notes_
Smoothing
16
Harmony Notes_Gender 17
Harmony
Notes_
Portamento
18
Harmony Attack 29
Harmony Release 31
Harmony HumanAmount 76
Harmony VibratoAmount 77
Harmony Hold_Release 78
Harmony Hold 80
Correct Shift 85
Transducer Filter 86
Doubling HumanAmount 87
11. Technical Specications
Eects Harmony, Double, Reverb, SFX
Pitch, Delay
Control Keys Scroll Encoder, Left/Right menu buttons
Home, Mix/Setup, Store, Genre
Construction Ridged, very low resonance
high impact polystyrene
Output connector 2 Standard ¼" jacks – mono/TS with
automatic mono/stereo sensing
One-click Friction Grip mic-stand
mounting system
Analog Inputs XLR/TRS combo jack
¼" guitar input
¼" pedal input
⁄" stereo aux input
Analog Outputs XLR mix output
Other USB, MIDI, Mic Control (TC HELICON MP-75/
76, Sennheiser E835FX)
Loudspeaker Full range 6.5" TANNOY 2-way coaxial
ICT Driver
Amplier 150W Class-D
150W Smart Power compensation and
cooperation
Power Power supply (supplied) 42.5V, 1.5A
Dimensions (H x W x D) 210 x 286 x 184 mm (8.25 x 11.25 x 7.25")
Weight 3 kg (6.6 lbs)
EMC: Complies with EN 55103-1 and EN 55103-2
FCC part 15, Class B, CISPR 22, Class B
Safety: Certied to IEC 65, EN 60065, UL6500 and CSA IEC 65, EN 60065,
UL6500 and CSA
