3.4 White Balance Adjustment
1. Input a black and white pattern to RF input.
2. Enter P-Mode, press key “3” to select white balance adjustment menu.
3. Use the color analyzer to measure the black side of the screen. Adjust the value of
“RC”,”GC” and “BC” to set the reading of the color analyzer to x=274, y=280. (11500 K).
4. Then measure the white side of the screen. Adjust the value of “RD”, “GD” and “BD” to
set the reading of the color analyzer to x=274, y=280. (11500 K).
5. Repeat step 3&4 until you can get the correct reading for both black and white sides.
Note:
A. The “SubBRI” and “SubCON” items are used to assistant the white balance adjustment.
It is the same function as the user OSD menu “Brightness” and “Contrast” items. You can
adjust these items to get the expect intensity when adjusting the white balance.
B. The “BLOR-Y”, “BLOG-Y” and “BLOB-Y” items are used for the YUV white balance
black level offset setup. When the TV white balance adjustment is done,
connect
a black and white pattern to YUV input terminal. Use the color analyzer to
measure the black side of the screen. Adjust the value of
the “BLOR-Y”, “BLOG-Y” and
“BLOB-Y” to set the reading of the color analyzer to x=274, y=280.
Table 3.4.1: The White Balance adjustment OSD menu
OSD menu Default Value Description Remark
RC 32 R cut-off setting(BLOR) Adjust to right value
GC 32 G cut-off setting(BLOG) Adjust to right value
BC 32 B cut-off setting(BLOB) Adjust to right value
RD 37 R drive setting(WPR) Adjust to right value
GD 32 G drive setting(WPG) Adjust to right value
BD 37 B drive setting(WPB) Adjust to right value
BLOC 8 Black level offset course(BLOC)
Adjust to right value accord
with the tube.
Recommended value= “8”
PWL 8 Peak White Limiting
Adjust to right value accord
with the tube.
Recommended value= “8”
BriVSD 32
Brightness of horizontal line when
adjust G2
Don’t adjust, use default
value “32” for producing
SubBRI 32 Brightness
SubCON 32 Contrast
Same as user “Brightness”
and “Contrast” adjust
BLOR-Y 64
BLOG-Y 62
BLOB-Y 64
YUV white balance black level
offset.
Adjust to right value accord
with the difference tube and
lot
BRTC 31 Sub-Brightness See section 3.5 for detailed
