TCL 21M63S-NX56E User Manual

TCL Multimedia Technology Holding CRT BU R&D Center
Chassis Name
NX56-AP&NX56B-AP
Serial No.
Issued on
2008-01-18
Page
Page 13 of 17
Updated on
2009-04-24
Version
4.0
B. Picture set to “Standard” status. (Brightness=50, Contrast=50, Colour=50, White
tone
=Normal.)
C.
Sound set normal.(Volume=30,Balance=50.)
D.
2). Set the user picture and sound curve value
A. Brightness curve:
OSD menu Default Value Description Remark
BRI0 0 Set the minimal brightness when user Brightness=0 Set to 3
BRI50 32 Set the brightness when user Brightness=50
BRI100 63 Set the maximal brightness when user Brightness=0
Use default value
B. C
ontrast curve:
OSD menu Default Value Description Remark
CON0 0 Set the minimal contrast when user Contrast=0 Set to 3
CON50 32 Set the contrast when user Contrast=50
CON100 63 Set the maximal contrast when user Contrast=0
Use default value
C. C
olour curve:
OSD menu Default Value Description Remark
COL0 0 Set the minimal colour when user Colour=0 Set to 3
COL50 32 Set the colour when user Color=50
COL100 63 Set the maximal colour when user Colour=0
Use default value
D. Volume
curve:
OSD menu Default Value Description Remark
VOL0 0 Set the volume when user Volume=0
VOL10 38 Set the volume when user Volume=10
Use default value
VOL30 65 Set the volume when user Volume=30 Set to 63
VOL50 71 Set the volume when user Volume=50 Set to 69
VOL80 77 Set the volume when user Volume=80 Set to 75
VOL100 83 Set the volume when user Volume=100 Set to 81
3). Set the value for “POWER LOW” and “POWER HIGH”
A. Connect the main voltage at low threshold 95VAC/50Hz.
B. Select item “POWER LOW”.
C. Adjust the value until the hint display just change between “AC: NORMAL” and “AC:
LOW”.
D. Connect the main voltage at high threshold 255VAC/50Hz.
E. Select item “POWER HIGH.
F. Adjust the value until the hint display just change between “AC: NORMAL” and “AC:
HIGH”.
