49" model
VESA 200 x 200, M6 x 12mm screws
•
50" model
VESA 200 x 200, M6 x 12mm screws
•
55" model
VESA 200 x 200, M6 x 12mm screws
•
65" model
VESA 400 x 200, M6 x 12mm screws
The VESA number is the horizontal and vertical measurement of the mounting holes.
For example, 100 x 200 indicates that the mounting holes are spaced 100mm
horizontally and 200mm vertically.
Follow the directions supplied with the wall mount to mount the TV to the wall.
Caution
: Your wall mount must be able to bear a minimum of five times the TVs net
weight to avoid damage.
Note
:
The wall mount bracket and the screws are not included
To use the stand
Your TCL Roku TV comes without the stands attached so that you can choose to use
the stands or mount your TV to a wall using a wall mount (sold separately). If you
want to mount your TV to the wall, don’t attach the stand legs.
A
– Place the TV face down on a soft, cushioned surface on a table. The bag the TV
was packed in makes a good cushion. Position the TV so that the stand, when
attached, will hang over the edge of the table.
B – Take out the two plastic covers from the stand holes at the bottom of the TV.
