EN
11
English
Chapter 4 - Using more of your TV
Installing channels
This section describes how to search and store
channels automatically. This may be done in any of
the cases below:
- you have skipped the channel installation step in the
initial setup;
- you are prompted that there are no channels in TV
mode;
- you want to update your channels.
1.
In TV mode, press
on the remote control
and select
Settings > Channels and inputs >
Channel > Channel scan
. Press
OK/
to enter.
2.
The TV installs and arranges channels according
to your country or region. Press
/
to select
Country/Region
, and press
OK/
to enter. Enter
the password you have set in the
Settings
>
System
>
Lock
menu. Press
/
to select your
country or region and press
OK
to conrm.
3.
Press
/
to select
Automatic search
and
press
OK
to enter.
4.
Press
/
to select
Tuner mode
and press
/
to select
Cable
,
Antenna
or
Satellite
.
(Note:
Satellite
option is available only in selected
models.)
5.
Press
/
to select other options to congure.
6.
After conguration is completed, press to select
Search
and press
OK
to start scanning channels.
7.
The channel search may take a few minutes. After
the automatic search, channels are arranged in a
preset order. If you want to edit the channel list,
press
on the remote control, select
Settings
> Channels and inputs > Channel > Edit
Channels
and press
OK
to enter.
Note:
Edit Channels
option is not available
when
Tuner mode
is set to
Antenna
and
Country/Region
is set to United Kingdom.
Common interface
Encrypted digital TV channels can be decoded with a
common interface module and a card provided by a
digital TV service operator.
The common interface module may enable several
digital services, depending on the operator and
services you choose (for example, pay TV). Contact
your digital TV service operator for more information
about services and terms.
Using the common interface module
WARNING: Switch o󰀨 your TV before inserting a
common interface module. Be sure to follow the
instructions described below. Wrong insertion of
a common interface module may damage both the
module and your TV.
1.
Following the directions printed on the common
interface module, gently insert the module into the
common interface slot on the TV.
2.
Push the module in as far as it will go.
3.
Turn on the TV and wait for the common interface
function to be activated. This may take several
minutes.
Note: Do not remove the common interface
module from the slot. Removing the module
will deactivate the digital services.
Accessing common interface services
After inserting and activating the common interface
module, press
on the remote control, select
Settings > Channels and inputs > Channel >
Common interface
and press
OK
to enter.
This menu option is only available if the common
interface module is correctly inserted and activated.
On-screen applications and content are provided by
your digital TV service operator.
Using subtitles
You can enable subtitles for each TV channel.
Subtitles are broadcast via Teletext or DVB-T/DVB-C/
DVB-S/DVB-T2/DVB-S2 digital broadcasts. With
digital broadcasts, you have the additional option of
selecting a preferred subtitle language.
Turning on/o󰀨 subtitles
1.
Press
on the remote control, select
Settings >
Channels and inputs > Channel > Subtitle
and
press
OK/
to enter.
2.
Select the
Subtitle
option, and press
OK
to toggle
between on or o󰀨.
3.
Press to return to the previous menu.
Enabling subtitle languages on digital TV
channels
1.
Press
on the remote control, select
Settings
> Channels and inputs > Channel > Subtitle >
Digital subtitle language 1st
and press
OK
/
to
enter.
2.
Press
/
to select a subtitle language as your
preferred language and press
OK
to conrm.
3.
Press
/
to select
Digital subtitle language
2nd
and press
OK
/
to enter.
4.
Press
/
to select a secondary subtitle
language and press
OK
to conrm.
5.
Press to return to the previous menu.

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the TCL 98P745 and is the answer not in the manual?

TCL 98P745 Specifications

General IconGeneral
AMD FreeSyncYes
Ambient modeIntelligent Picture
Game featuresAuto Low Latency Mode (ALLM), Game Master Pro, Gamebar 2.0, HGiG, Variable Refresh Rate (VRR)
NVIDIA G-SYNCNo
Processor cores4
AMD FreeSync typeFreeSync Premium Pro
Audio formats supportedMP3, WMA
Image formats supportedBMP, HEIF, JPG
Video formats supportedAVI, H.264, H.265, MKV, MP4, MPG, TS, VP9, WEBM, WMV
Video compression formatsH.264, H.265, MPEG2
Picture processing technologyTCL AiPQ 3.0 Processor
High Dynamic Range (HDR) technologyDolby Vision IQ, High Dynamic Range 10 (HDR10), High Dynamic Range 10+ (HDR10 Plus), Hybrid Log-Gamma (HLG)
Music appsSpotify, TIDAL, YouTube Music
Video appsAmazon Prime Video, Apple TV, Disney+, HBO, Netflix, Twitch, YouTube
Smart modesDolby Vision, Dolby Vision Bright, Dolby Vision Dark, Dynamic, Energy saving, Game, Movie, Normal, Smart HDR, Sports, Standard
Lifestyle appsGoogle Apps
Operating system version11.0
App distribution platformGoogle Play
Operating system installedGoogle TV
Hybrid Broadcast Broadband TV (HbbTV) version2.0.3
Pallet length255 mm
Pallet net width2395 mm
Pallet net height1570 mm
Pallet net weight99000 g
Quantity per truck52 pc(s)
Quantity per pallet1 pc(s)
Master (outer) case height1550 mm
Master (outer) case weight88000 g
Cord length1.5 m
User memory18.7 GB
Battery weight15 g
Power plug typeType E
Warranty period2 year(s)
Country of originPoland
Battery technologyAlkaline
Processor frequency1.4 GHz
Processor architectureARM Cortex-A73
Audio (L/R) out1
RF connector typeF, IEC
RF ports quantity2
USB 2.0 ports quantityUSB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Consumer Electronics Control (CEC)T-link
Common interface Plus (CI+) version1.4
Wi-Fi standards802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac)
Bluetooth version5.0
Browser supported-
Bluetooth profilesA2DP, HID
Package depth245 mm
Package width2384 mm
Package height1430 mm
Package weightWeight of the packaged product in gram.
Color depth10 bit
Screen shapeFlat
Display diagonal98 \
Anti-glare screenAlways gives an optimal view, even in direct sunlight.
Display brightness350 cd/m²
Display resolution3845 x 2160 pixels
Display technologyLED
Native aspect ratio16:9
Native refresh rate144 Hz
Peak luminance ratio65 %
LED backlighting typeDirect-LED
Supported video modes2160p
Display diagonal (metric)215.9 cm
Motion interpolation technologyPPI (Picture Perfomance Index) 3000
Dynamic contrast ratio marketing nameMega Contrast
Stand typeLegs stand
Product colorBlack
Heavy metals freeCd (cadmium)
Panel mounting interface850 x 400 mm
Cables includedAC
Remote control typeRC833
Audio decodersDTS, Dolby Atmos, DTS Virtual:X, DTS:X
RMS rated power60 W
Audio output channels2.0 channels
Equalizer bands quantity7
Tuner typeAnalog & digital
Number of tuners1 tuner(s)
Analog signal format systemNTSC, PAL BG, PAL DK, PAL I, SECAM B/G, SECAM D/K
Digital signal format systemDVB-C, DVB-S2, DVB-T2
Control typeButtons
Programming period8 day(s)
Number of OSD languages29
Firmware upgradeable viaNetwork, USB
On Screen Display (OSD) languagesALB, BUL, CRO, CZE, DAN, DEU, DUT, ENG, ESP, EST, FIN, FRE, GRE, HUN, ITA, LAT, LIT, MAC, NOR, POL, POR, RUM, RUS, SER, SLK, SLV, SWE, TUR, UKR
AC input voltage220-240 V
AC input frequency50/60 Hz
Power consumption (standby)0.5 W
Power consumption (typical)- W
Weight and Dimensions IconWeight and Dimensions
Depth (with stand)429 mm
Width (with stand)2179 mm
Height (with stand)1288 mm
Weight (with stand)58000 g
Depth (without stand)68 mm
Height (without stand)1247 mm
Weight (without stand)55400 g
