EN
5
English
Connect the power and antenna
To switch on TV after connecting power cord, press or
POWER/
.
Notes:
- Position of power socket varies according to TV model.
- Disconnect the power cord before connecting devices.
Cable
Chapter 1 - Connections
(Optical)
Digital
audio out
USB 3.0
5V 0.9A
MAX
LAN
(Service port)
HDMI 1 (4K@144Hz) HDMI 2 (4K@120Hz)
eARC/ARC
Antenna/Cable input
Satellite input
13/18V 0.4A
MAX
AV adapter
Common interface
HDMI 3 (4K@60Hz) HDMI 4 (4K@60Hz)
HD game
console
Blu-ray Disc
player
HD Camcorder
Connect Blu-ray Disc player, HD game console, HD camcorder, headphones,
CI module

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the TCL 98P745 and is the answer not in the manual?

TCL 98P745 Specifications

General IconGeneral
AMD FreeSyncYes
Ambient modeIntelligent Picture
Game featuresAuto Low Latency Mode (ALLM), Game Master Pro, Gamebar 2.0, HGiG, Variable Refresh Rate (VRR)
NVIDIA G-SYNCNo
Processor cores4
AMD FreeSync typeFreeSync Premium Pro
Audio formats supportedMP3, WMA
Image formats supportedBMP, HEIF, JPG
Video formats supportedAVI, H.264, H.265, MKV, MP4, MPG, TS, VP9, WEBM, WMV
Video compression formatsH.264, H.265, MPEG2
Picture processing technologyTCL AiPQ 3.0 Processor
High Dynamic Range (HDR) technologyDolby Vision IQ, High Dynamic Range 10 (HDR10), High Dynamic Range 10+ (HDR10 Plus), Hybrid Log-Gamma (HLG)
Music appsSpotify, TIDAL, YouTube Music
Video appsAmazon Prime Video, Apple TV, Disney+, HBO, Netflix, Twitch, YouTube
Smart modesDolby Vision, Dolby Vision Bright, Dolby Vision Dark, Dynamic, Energy saving, Game, Movie, Normal, Smart HDR, Sports, Standard
Lifestyle appsGoogle Apps
Operating system version11.0
App distribution platformGoogle Play
Operating system installedGoogle TV
Hybrid Broadcast Broadband TV (HbbTV) version2.0.3
Pallet length255 mm
Pallet net width2395 mm
Pallet net height1570 mm
Pallet net weight99000 g
Quantity per truck52 pc(s)
Quantity per pallet1 pc(s)
Master (outer) case height1550 mm
Master (outer) case weight88000 g
Cord length1.5 m
User memory18.7 GB
Battery weight15 g
Power plug typeType E
Warranty period2 year(s)
Country of originPoland
Battery technologyAlkaline
Processor frequency1.4 GHz
Processor architectureARM Cortex-A73
Audio (L/R) out1
RF connector typeF, IEC
RF ports quantity2
USB 2.0 ports quantityUSB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Consumer Electronics Control (CEC)T-link
Common interface Plus (CI+) version1.4
Wi-Fi standards802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac)
Bluetooth version5.0
Browser supported-
Bluetooth profilesA2DP, HID
Package depth245 mm
Package width2384 mm
Package height1430 mm
Package weightWeight of the packaged product in gram.
Color depth10 bit
Screen shapeFlat
Display diagonal98 \
Anti-glare screenAlways gives an optimal view, even in direct sunlight.
Display brightness350 cd/m²
Display resolution3845 x 2160 pixels
Display technologyLED
Native aspect ratio16:9
Native refresh rate144 Hz
Peak luminance ratio65 %
LED backlighting typeDirect-LED
Supported video modes2160p
Display diagonal (metric)215.9 cm
Motion interpolation technologyPPI (Picture Perfomance Index) 3000
Dynamic contrast ratio marketing nameMega Contrast
Stand typeLegs stand
Product colorBlack
Heavy metals freeCd (cadmium)
Panel mounting interface850 x 400 mm
Cables includedAC
Remote control typeRC833
Audio decodersDTS, Dolby Atmos, DTS Virtual:X, DTS:X
RMS rated power60 W
Audio output channels2.0 channels
Equalizer bands quantity7
Tuner typeAnalog & digital
Number of tuners1 tuner(s)
Analog signal format systemNTSC, PAL BG, PAL DK, PAL I, SECAM B/G, SECAM D/K
Digital signal format systemDVB-C, DVB-S2, DVB-T2
Control typeButtons
Programming period8 day(s)
Number of OSD languages29
Firmware upgradeable viaNetwork, USB
On Screen Display (OSD) languagesALB, BUL, CRO, CZE, DAN, DEU, DUT, ENG, ESP, EST, FIN, FRE, GRE, HUN, ITA, LAT, LIT, MAC, NOR, POL, POR, RUM, RUS, SER, SLK, SLV, SWE, TUR, UKR
AC input voltage220-240 V
AC input frequency50/60 Hz
Power consumption (standby)0.5 W
Power consumption (typical)- W
Weight and Dimensions IconWeight and Dimensions
Depth (with stand)429 mm
Width (with stand)2179 mm
Height (with stand)1288 mm
Weight (with stand)58000 g
Depth (without stand)68 mm
Height (without stand)1247 mm
Weight (without stand)55400 g
