TCL 98P745 User Manual

EN
6
English
Connections
Notes:
-
Your TV might not have all connectors visible on diagram above. Number of USB and HDMI ports may vary
according to TV model.
-
Button and connector locations may vary according to TV model.
-
USB connectors are for data input from USB drives and for connecting other relevant USB devices where
applicable.
-
All USB devices have to be directly connected to TV set without cable extenders. In case extender is
required, maximum 50cm length is recommended. Longer extenders should have ferrite beads.
-
eARC/ARC (enhanced Audio Return Channel/Audio Return Channel) function is only supported on the HDMI
port identied with eARC/ARC. To use eARC/ARC function, please turn on
CEC
function rst as described in
the
CEC
section.
-
It is recommended to use high quality and well shielded HDMI cables to avoid possible interferences.
-
Please use headphones with 3.5mm TRS connector. Excessive sound pressure from headphones can cause
hearing loss.
Connect to the Internet
Wired connection
Wireless connection
Router
Modem Internet
LAN port
Modem Internet
Wireless router
Note: The following instructions are just the usual ways to connect your TV to the wired or wireless network.
The connection method may be dierent depending on your actual network conguration. If you have any
questions about your home network, please refer to your Internet service provider.
Network settings:
1.
Press on the remote control to display the dashboard menu.
2.
Select
Settings
and press
OK
to enter the settings menu.
3.
Press
/
to select
Network and Internet
, press
OK
to enter the submenu and follow the on-screen
guidance to set up your network.

TCL 98P745 Specifications

General

AMD FreeSync	Yes
Ambient mode	Intelligent Picture
Game features	Auto Low Latency Mode (ALLM), Game Master Pro, Gamebar 2.0, HGiG, Variable Refresh Rate (VRR)
NVIDIA G-SYNC	No
Processor cores	4
AMD FreeSync type	FreeSync Premium Pro
Audio formats supported	MP3, WMA
Image formats supported	BMP, HEIF, JPG
Video formats supported	AVI, H.264, H.265, MKV, MP4, MPG, TS, VP9, WEBM, WMV
Video compression formats	H.264, H.265, MPEG2
Picture processing technology	TCL AiPQ 3.0 Processor
High Dynamic Range (HDR) technology	Dolby Vision IQ, High Dynamic Range 10 (HDR10), High Dynamic Range 10+ (HDR10 Plus), Hybrid Log-Gamma (HLG)
Music apps	Spotify, TIDAL, YouTube Music
Video apps	Amazon Prime Video, Apple TV, Disney+, HBO, Netflix, Twitch, YouTube
Smart modes	Dolby Vision, Dolby Vision Bright, Dolby Vision Dark, Dynamic, Energy saving, Game, Movie, Normal, Smart HDR, Sports, Standard
Lifestyle apps	Google Apps
Operating system version	11.0
App distribution platform	Google Play
Operating system installed	Google TV
Hybrid Broadcast Broadband TV (HbbTV) version	2.0.3
Pallet length	255 mm
Pallet net width	2395 mm
Pallet net height	1570 mm
Pallet net weight	99000 g
Quantity per truck	52 pc(s)
Quantity per pallet	1 pc(s)
Master (outer) case height	1550 mm
Master (outer) case weight	88000 g
Cord length	1.5 m
User memory	18.7 GB
Battery weight	15 g
Power plug type	Type E
Warranty period	2 year(s)
Country of origin	Poland
Battery technology	Alkaline
Processor frequency	1.4 GHz
Processor architecture	ARM Cortex-A73
Audio (L/R) out	1
RF connector type	F, IEC
RF ports quantity	2
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Consumer Electronics Control (CEC)	T-link
Common interface Plus (CI+) version	1.4
Wi-Fi standards	802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac)
Bluetooth version	5.0
Browser supported	-
Bluetooth profiles	A2DP, HID
Package depth	245 mm
Package width	2384 mm
Package height	1430 mm
Package weight	Weight of the packaged product in gram.
Color depth	10 bit
Screen shape	Flat
Display diagonal	98 \
Anti-glare screen	Always gives an optimal view, even in direct sunlight.
Display brightness	350 cd/m²
Display resolution	3845 x 2160 pixels
Display technology	LED
Native aspect ratio	16:9
Native refresh rate	144 Hz
Peak luminance ratio	65 %
LED backlighting type	Direct-LED
Supported video modes	2160p
Display diagonal (metric)	215.9 cm
Motion interpolation technology	PPI (Picture Perfomance Index) 3000
Dynamic contrast ratio marketing name	Mega Contrast
Stand type	Legs stand
Product color	Black
Heavy metals free	Cd (cadmium)
Panel mounting interface	850 x 400 mm
Cables included	AC
Remote control type	RC833
Audio decoders	DTS, Dolby Atmos, DTS Virtual:X, DTS:X
RMS rated power	60 W
Audio output channels	2.0 channels
Equalizer bands quantity	7
Tuner type	Analog & digital
Number of tuners	1 tuner(s)
Analog signal format system	NTSC, PAL BG, PAL DK, PAL I, SECAM B/G, SECAM D/K
Digital signal format system	DVB-C, DVB-S2, DVB-T2
Control type	Buttons
Programming period	8 day(s)
Number of OSD languages	29
Firmware upgradeable via	Network, USB
On Screen Display (OSD) languages	ALB, BUL, CRO, CZE, DAN, DEU, DUT, ENG, ESP, EST, FIN, FRE, GRE, HUN, ITA, LAT, LIT, MAC, NOR, POL, POR, RUM, RUS, SER, SLK, SLV, SWE, TUR, UKR
AC input voltage	220-240 V
AC input frequency	50/60 Hz
Power consumption (standby)	0.5 W
Power consumption (typical)	- W

Weight and Dimensions

Depth (with stand)	429 mm
Width (with stand)	2179 mm
Height (with stand)	1288 mm
Weight (with stand)	58000 g
Depth (without stand)	68 mm
Height (without stand)	1247 mm
Weight (without stand)	55400 g
