5.6 Disassembly process evaluation
We list the POP4-10 4G&VF parts disassembly time, technique levels and disassembly methods as below,
for technique levels, Class 1 signifies easy to disassembly, Class 2 signifies normal to disassembly and
Class 3 signifies hard to disassembly.
Spare part
Time for
disassembly
Jigs for
disassembly
Difficulty Class
Remark
Furnished battery cover
6s
Plastic flake
Class 2
Screws
20s
Screwdriver
Class 1
Main PCBA
15s
Tweezers
Plastic Flake
Class 2
Main camera
2s
Screwdriver
Plastic Flake
Class 1
Front Camera
2s
Plastic Flake
Class 1
Battery
10s
Plastic Flake
Class 2
Speakers
10s
Tweezers+
soldering iron
Class 2
FPCs
4s
Tweezers
Class 1
MIC rubber
2s
Tweezers
Class 1
6 Disassembly Complete
 Explored view
Please get the explore view from TS website: https://css.tclmobile.cn/.
 Please get the latest SPL in Forlog system.
7 Level 2 repair
This chapter describes the Level 2 repair that can be done without any diagnostic equipment.
