1.1 7100 / 7150 SPECIFICATIONS
Specifications
Right Hand
Chute
Sloping Swivel
Chute
Dual Chop
Chamber width 1.4m
Giraffe discharge height N/A 3.5m 3.5m
Giraffe rotation angle N/A 280 degrees 280 degrees
Side discharge height 1.7m N/A N/A
Overall width (chutes closed) 2.2m 1.86m 1.86m
Maximum overall width 2.9m 2.75m 2.75m
Overall height - maximum 2.3m 3.6m 3.6m
Overall height - minimum 2.11m 2.4m 2.4m
Overall length - tailgate up 2.71m
Overall length - tailgate down 3.95m
Maximum round bale diameter 1.83m
Maximum rectangular bale size 1.3m x 1.2m x 2.5m
Weight 1620kg 1680kg 1820 kg
Maximum hydraulic oil pressure 220 bar (3190 psi)
Maximum hydraulic oil flow 60 litres/minute (13.2 gal/min)
Minimum hydraulic oil flow 35 litres/minute (7.7 gal/min)
Time averaged sound power 92dBA 92dBA 92dBA
Minimum tractor size 70Kw (90hp)
Vertical load at hitching point - un-laden 1620kg 1680kg 1820kg
Vertical load at hitching point - laden 2420kg 2480kg 2620kg
Model 7100 7100SC 7150
Machine Fitted With Drawbar & Axle
Specifications T7100 T7100SC T7150
Overall width 2.38m 2.2m 2.2m
Weight 1805kg 1865kg 2005kg
Maximum drawbar load 325kg 325kg 365kg
Wheel track
1.75m
Machine Fitted With Castor Wheels
Specifications T7100 T7100SC T7150
Weight 1757kg 1817kg 1957kg
Wheel size 18x7-8
Wheel track 1.09m
Wheel speed rating 25 km/h
Maximum journey distance 2 km
Load rating per wheel 1650 kg
7
