10 Schematic Diagram
TOP PREVIOUS NEXT
(All schematic diagrams may be modified at any time with the development of new technology.)
Notes:
S301 VCR2/VCR3 Switch
S901 Power Switch
S902 Speaker B Switch
S903 Band Switch
S904 FM Mode Switch
S905 Tuning Down Switch
S906 Tuning Up Switch
S907 Memory Switch
S908 Preset Switch
S909 DSP Sound Mode Switch
S911 Speaker A Switch
S912 Bi-Wire Switch
S913 VGCA Switch
S914 DVD 6CH Input Switch
S917 Digital Input Switch
S918 Tape Monitor Switch
The voltage value and waveforms are the reference voltage of this unit measured by DC electronic
voltmeter (high impedance) and oscilloscope on the basis of chassis. Accordingly, there may arise some
error in voltage values and waveformsdepending upon the internal impedance of the tester or the
measuring unit.
< > ...FM
( ) ...AM
Importance safety notice:
Components identifed by
mark have special characteristics important for safety. Furthermore, special
parts which have purposes of fire-retardant (resistors), high-quality sound (capacitors), low-noise
(resistors), etc. are used. Whenreplacing any of components, be sure to use only manufacturer’s specified
parts shown in the parts list.
