Chapter 1 Checking and Installing
1-1 Checking Products
Our Servo Pack have already completely been functionally examined before leaving the factory. In order to
protect the products from the damage during transportation, please check the items below before sealing off
the pack:
Check if the models of servo driver and motor are the same with the models of ordering.
(About the model explanation, please check the chapters below)
Check if there are damage or scrape out side of the servo driver and motor.
(If there is any damage during transportation, do not power ON)
Check if there are any bad assembly or slipped component in the Servo Drive and Motor
Check if the Motor’s rotor and shaft can be rotated smoothly by hand
(The Servo Motor with Mechanical-Brake can not be rotated directly)
There must be the “QC”-seal in each servo drive, if not, please do not proceed Power ON.
If there is any bug or irregular under the situation above, please contact TECO’s Local sales representative
or distributor instantly.
1-1-1 Confirming with Servo Drives
JSD EP – 15 A
TECO AC Servo
Product No.
Drive Series:
EP Series
Drive Model:
15 / 20 / 30 / 50 / 75
AC Input Voltage
A : AC 220V
Input voltage phase:
□
□□
□：
：：
：
Single / Three
3
：
：：
：
3 Phase input
P.S : Maximum output power
10 : 100 W 30 : 1 KW
15 : 400 W 50 : 2KW
20 : 750 W 75 : 3 KW
