CHAPTER 8
ENGINE SPECIFICATIONS AND
SEARS CRAFTSMAN CROSS-REFERENCE
Inch lbs. Ft. Lbs. Nm
Crankcase Cover to Crankcase 85 7 10
Cylinder Block to Crankcase 88 7 10
Spark Plug 230 19 26
Flywheel Nut 210 17.5 24
Solid State Mounting Bolts 35 3 4
Blower Housing Base to Crankcase 35 3 4.0
Starter Retainer Screw 35 3 4
Carburetor to Block 35 3 4
Air Vane to Carburetor 4 - .5
Starter Pawl to Flywheel 73 6 8.5
Muffler to Cylinder 95 8 11
A/C Cover TC Type II 4 - .5
Filter/Tank to Carburetor 23 2 2.6
Fuel Tank to Housing 23 2 2.6
Type II Speed Control to base 35 3 4
TC TORQUE SPECIFICATIONS
The torque specifications listed in this chart are to be used for replacing components after disassembly, not for checking
an existing engine bolt torque. Checking a torque value on a new or used engine may be lower due to torque relaxation
that occurs on all engines from thermal expansion and contraction. However, sufficient clamping force exists and a re-
torque is not necessary.
