CFG253 User Manual
9
Appendix A: Specifications
Table 2 shows characteristics of the CFG253 Function Generator that
are guaranteed by warranty.
:
nt
d Ch
ct
st
cs
Characteristic
Measurement
Outputs Square wave, sine wave, sawtooth wave, TTL
pulse, and sweep functions for all outputs
Line Voltage Range 90 to 110, 108 to 132, 198 to 242, and 216 to 250 VAC at
50–60 Hz
Frequency ranges,
nonskewed
waveform (Freq/1)
Frequency ranges,
skewed waveform (Freq/10)
Frequency multiplier Variable 0.3 to 3.0 times the selected frequency
range
Frequency/1 dial accuracy ±5% of full scale of frequency/1
Frequency/10 dial accuracy ±5% of full scale of frequency/10
Sine wave distortion <1% from 10 Hz to 100 kHz
