Analyze Waveform Data
3. Use the side-b ezel menu and the multipurpose
knobs to adjust the vertical and horizontal
settings of the reference waveform.
R1
Vertical
0.00 div
100 mV/div
Horizontal
0.00 s
4.00 μs/div
Quick Tips
Selecting and Displaying Reference Waveforms. You can display all the reference wavefo rms at the same time. Push the
appropriate scree n button to select a particular reference waveform.
Removing Reference Waveforms from the Display. To remove a reference w aveform from the d isplay, push the front-panel
R but ton to access the lower-bezel menu. The n push the asso ciat ed button from the lower-bezel menu t o turn it off.
Scaling and Positioning a Reference Waveform. You can position and scale a reference waveform independently from
all other displayed waveforms. Select the reference w aveform and then adjust it with a multipurpose knob. You can do this
whether acquisition is running or not.
If a reference waveform is selected, scaling and repositioning of the reference waveform operates the same way whether zoom
is turned on or off.
MSO4000 and DPO4000 Series Oscilloscopes User Manual 223
