Tektronix DPO7354C User Manual

Display a wavefo
rm
Selecting the Waveform Interpolation
Select Displa
y > Waveform Interpolation,
and then select one of the following:
Sin(X)/X interpolation computes record
points using a curve fit between the
actual sampl
es acquired.
Linear inter
polation computes record
points between actual acquired samples
by using a straight line fit.
Quick tips
Sin(X)/X interpolation is the default interpolation mode. It requires fewer actual sample points than linear interpolation to
accurately represent the waveform.
94 MSO/DPO70000DX, MSO/DPO70000C, DPO7000C, and MSO/DPO 5000B Series U ser M anual
