Tektronix MSO4000B Series Technical Reference

Specifications
Mechanical Sp
ecifications
The following table shows the mechanical specifications for the MSO4000B
Series and DPO4000B Series oscilloscopes.
Table 12: Me
chanical specifications
Characteristic Description
Dimensions
Benchtop configuration (oscilloscope only)
Requirements that follow are nominal and unboxed
Height:
9.0 in (229 mm) feet folded in, handle folded down
9.8 in (249 mm) feet folded out, handle folded down
11.5 in (2
92 mm) feet folded in, handle folded up
12.3 in (312 mm) feet folded out, handled folded up
Width:
17.3in(4
39 mm) from handle hub to handle hub
Depth:
5.8 in (147 mm) from back of feet to front of knobs
6.1in(1
55 mm) from back of feet to front of front cover
9.8 in (249 mm) from handle to front of knobs (handle folded to backside of unit)
Box Dimensions:
Height
: 15.7 in (399 mm)
Width: 15.6 in (396 mm)
Length: 22.2 in (564 mm)
Rackmo
unt configuration
Requirements that follow are nominal and unboxed (5U rack sizes):
Height: 8.6 in ( 218 mm)
Width
: 19.2 in ( 488 mm), from outside of handle to outside of handle
Depth: 15.1 in (384 mm), from outside of handle to back of slide
Weigh
t
Benchtop configuration (oscilloscope only)
Requirements that follow are nominal:
11.0
lbs (5.0 kg), stand-alone instrument, without front cover.
18.8 lbs (8.5 kg), instrument with rackmount, without front cover
23.6 lbs (10.7 kg), when packaged for domestic s hipment (without rackmount)
Cle
arance Requirements
0mm
(0 in), top
0 in (0 mm), bottom, on feet, with flip stands down
2 in (50.8 mm), left side (facing the front of the instrument)
0i
n (0 mm), right side (facing the front of the instrument)
2 in (50.8 mm), rear (where the power cord is plugged in)
