Tektronix MSO4000B Series Technical Reference

Performance Verification
Delta Time Meas
urement Accu racy
All four-chan
nel and <1 GHz models
(DPO4054B, DPO4034B, DPO4014B)
Channel 4
DPO = 4 ns/Div, Source freq = 240 MHz (except DPO4014B)
DPO V/Div Source V
pp
Test result High limit
5 mV 40 mV 234 ps
100 mV 800 mV 233 ps
500 mV 4 V 233 ps
1 V 4 V 237 ps
DPO = 40 ns
/Div, Source freq = 24 MHz
1 mV 8 mV 736 ps
5 mV 40 mV 423 ps
100 mV 800 mV 357 ps
500 mV 4 V 354 ps
1 V 4 V 581 ps
DPO = 400 ns/Div, Source freq = 2.4 MHz
1 mV 8 mV 6.99 n
s
5mV 40mV 3.54ns
100 mV 800 mV 2.73 ns
500 m
V
4 V 2.69
ns
1 V 4 V 5.34 ns
DPO = 4 μs/Div, Source freq = 240 kHz
1 mV 8 mV 69.9 ns
5m
V
40
mV
35
.4 ns
100 mV 800 mV 27.3 ns
500 mV 4 V 26.9 ns
1
V
4
V
5
3.4 ns
D
PO = 40 μs/Div, Source freq = 24 kHz
1 mV 8 mV 699 ns
5 mV 40 mV 354 ns
100 mV 800 mV 273 ns
500 mV 4 V 269 ns
1 V 4 V 534 ns
DPO = 400 μs/Div, Source freq = 2.4 kHz
1 mV 8 mV 6.99 s
5mV 40mV 3.54s
100 mV 800 mV 2.73 s
500 mV 4 V 2.69 s
1 V 4 V 5.34 s
MSO4000B and DPO4000B Series Specifications and Performance Verification 51
