Tektronix MSO4032 Technical Reference

Specifications
Table 4: Trigger specifications (cont.)
Characteristic Description
FlexRay
4
Indicator bits: Normal Frame, Payload Frame, Null Frame, Sync Frame, Startup Frame
Identifier Trigger: 11 bits of user-specified data, equal to (=), not equal to (<>), less than (<),
greater than (>), less than or equal to (<=), greater than or equal to (>=), Inside Range, or
Outside Range
Cycle Count Trigger: 6 bits of user-specified data, equal to (=)
Header Fields Trigger: 40 bits of user-specified data comprising Indicator Bits, Identifier,
Payload Length, Header CRC, Cycle Count, or equal to (=)
Data Trigger: 1 to 16 Bytes of user-specified data, with 0 to 253, or "don't care" bytes of data
offset, including qualifiers of equal to (=), not equal to <>, less than (<), greater than (>), less
than or equal to (<=), greater than or equal to (>=), Inside Range, Outside Range
End Of Frame: User-chosen types S tatic, Dynamic (DTS), and All
Error: Header CRC, Trailer CRC, Null Frame-static, Null F rame-dynamic, S ync Frame,
Startup Frame
Trigger On: Start of Frame, Indicator Bits, Identifier, Cycle Count, Header Fields, Data,
Identifier & Data, End of Frame, or Error
Maximum Data Rate: 10 Mbps
I
2
S
4
Data Trigger: 32 bits of user-specified data in a left word, right word, or either, including
qualifiers o f equal to (=), not equal to <>, less than (<), greater than (>), less than or equal to
(<=), greater than or equal to (>=), inside range, outside range
Trigger on: Word Select, Data
Maximum Data Rate: 12.5 Mbps
Left J ustified
4
Data Trigger: 32 bits of user-specified data in a left word, right word, or either, including
qualifiers o f equal to (=), not equal to <>, less than (<), greater than (>), less than or equal to
(<=), greater than or equal to (>=), inside range, outside range
Trigger on: Word Select, Data
Maximum Data Rate: 12.5 Mbps
Right Justified
4
Data Trigger: 32 bits of user-specified data in a left word, right word, or either, including
qualifiers o f equal to (=), not equal to <>, less than (<), greater than (>), less than or equal to
(<=), greater than or equal to (>=), inside range, outside range
Trigger on: Word Select, Data
Maximum Data Rate: 12.5 Mbps
TDM
4
Data Trigger: 32 bits of user-specified data in a channel 0-7, including qualifiers of equal to
(=), not equal to <>, less than (<), greater than (>), less than or equal to (<=), greater than or
equal to (>=), inside range, outside range
Trigger on: Frame Sync, Data
Maximum Data Rate: 25 Mbps
1
For logic, time between channels refers to the length o f time a logic state derived from more than one channel must exist to be recognized. For events, thetime
is the minimum time between a main and delayed event that will be recognized if more than one channel is used.
2
A
n active pulse width is the width of the clock pulse from its active edge (as defined through the Define Inputs lower-bezel button and the Clock Edge side-bezel
menu) to its inactive edge. An inactive pulse width is the width of the pulse from its inactive edge to its active edge.
3
The User hold time is the number selected by the user through the Times lower-bezel button and the Hold Time side-bezel menu.
4
DPO4000 Series: S/N CO20000/B020000 and above; MSO4000 Series: all units.
12 MSO4000 and DPO4000 Series Specifications and Performance Verification

Tektronix MSO4032 Specifications

General

Brand	Tektronix
Model	MSO4032
Category	Test Equipment
Language	English
