Tektronix TDS 684A User Manual

Measuring Waveforms
3–114
TDS 500B, TDS 600B, & TDS 700A User Manual
Table 3–10 shows the action the oscilloscope takes based on the probe connected
and user operation performed.
Table 3–10: Probe Cal Status
Probe Cal’d?
1
User Action
Type Probe Connected
2
Probe Cal’d?
1
User Action
Simple Interface
3
TEKPROBE Interface
4
No Doesn’t Matter Initialized Initialized
Yes Power off Initialized
(probe data is retained)
Initialized
(probe data is retained)
Yes Power on Can not detect differ-
ent probe:
Display Re-use Probe
Calibration Data menu
Cal’d Probe: Pass
Different probe: Initialized Different probe: Initialized
Yes Disconnect Probe Initialized Initialized
Yes Connect Probe Can not detect differ-
ent probe:
Display Re-use Probe
Calibration Data menu
Cal’d Probe: Pass
Different probe: Initialized Different probe: Initialized
1
Refers to a channel input that was successfully compensated at the time Probe Cal was last executed for the input channel.
2
If no probe is connected, the probe status in the vertical main menu is always initialized.
3
A probe with a simple interface is a probe that can convey very limited information to the oscilloscope. Most passive
probes (such as the P6139A) have simple interfaces.
4
A probe with a TEKPROBE interface is a probe that can convey additional information. For instance, it might automatical-
ly set the oscilloscope input channel impedance to match the probe, send the oscilloscope a unique probe identification
number, and so on. Some optical probes and most active probes (such as the P6205) have TEKPROBE interfaces.
