Maintenance
TDS3000B Series Service Manual
6-37
6. Remove the front-panel and bezel button keypads by lifting them away from
the front panel. Do not touch the keypad contacts or place them on a
contaminated surface. See Figure 6--25.
Front panel keypad
Bezel keypad
Figure 6- 25: Remove front-panel keypads
