Basic Installation
Figure 3:
Connecting the P64xx logic analyzer probes
First Time Operation
CAUTION. Connect the keyboard, mouse, and other accessories before applying
power to the logic analyzer. Connecting the accessories after turning on the logic
analyze
r can damage the accessories.
TLA5000 Series Logic Analyzer Installation M anual 5
