Tektronix WVR6020 Service Manual

Replaceable Parts
Fig. &
index
number
Tektronix part
number
Serial no.
effective
Serial no.
discont’d Qty Name & description
5-2
CABLES, CONNECTORS, ETC.
-1 174-5224-00 1
CA ASSY,SP; PWR,BR;10.250 L;18 AWG;CONN HDR 1 X 8 AND CONN
HDR 1 X12 AND 1X2;PWR SUPPLY TO MAIN BD AND EYE BDS
-2 174-4769-00 1
CA ASSY,SP; HV,BR,15.00 L & 4.00 L;CONN EACH END;LINE FILTER
TO PWR SUPPLY,SAFETY CONTROLLED
-3 260-5012-00 1
SWITCH,DIP; SPST,SLIDE,DIP,4 POSITION,GOLD OVER NICKEL,0.4VA
@ 20VDC,0.05 HALF PITCH;TD04H0SK1,SMD
-4 134-0246-00 12
1
PLUG,HOLE COVER; BUTTON PLUG,;0.578 HEAD DIA X 0.406
THK,ACCOM 0.5 DIA HOLE,0.015-0.125 THK PNL,NYLON,BLACK
-5
131-7270-00 10
1
CONN,RF PLUG; BNC,PCB,PNL MNT,FEMALE,RTANG,75 OHM, 0.510
H X 0.169 TAIL,LOW PROFILE ZINC DIE CAST HOUSING
-6 210-1039-00 10
1
WASHER,LOCK; 0.521 ID,INT,0.025 THK,SST
-7
220-0497-00 10
1
NUT,PLAIN,HEX; 0.5-28 X 0.562 HEX,BRS CD PL
-8 119-5067-00 4
FILTER,RFI; EMI, COMMON MODE CHOKE COIL; 2LINES, 200 0HM
IMP, 20- 300MHZ, 50V, 0.5A; 8 PIN SMD; ZJYS51R5-4P
-9 131-7257-00 1
CONN,JACK; PCB/PNL,RJ45,CAT5,W/LEDS YELLOW &
GREEN,FEMALE,RTANG,8 POS,0.1 CTR,0.528 H X 0.138 TAIL,10/100
BASE TX AND RX MAGNETICS MODULE,SAFETY CONTROLLED
-10 260-5015-00 1
SWITCH,PUSH; SPST,TACT;50MA,50V,MOMENTARY,SILVER
CONTACTS;KSC221G,GULLWING SMD,T&R
-11 131-3572-00 1
CONN,HDR:; PCB,;MALE,STR,2 X 7,0.1 CTR,0.385 H X 0.120
TAIL,SHRD/4 SIDES,CTR PLZ,30 GOLD,0.150 END DIM;,,
-12 260-5000-00 1
SWITCH,SLIDE; SPST;DIP8 POSITION,GOLD OVER
NICkEL,3A,2PF,SEALED;90HBW08S
-13 150-1022-00 1
DISPLAY,OPTO; ,LED;RED,660NM,7SEG,0.3 INCH DISPLAY,125UCD
PER SEGMENT AT10MA,COMMON ANODE,LEFT HAND
DECIMAL;MAN72A
-14 1
FUSE; UL/IEC127, F3.15A H, 250VAC (5 x 20 m m)
-15 131-6187-00 1
CONN,HDR PWR; PCB,MALE,STR,1 X 8,0.156 CTR,0.450 MLG X 0.125
TAIL,PLZ WALL,TIN,SAFETY CONTROLLED
-16 131-7244-00 2
CONN,HDR; SMD,MALE,STR,2 X 5,0.100 CTR,0.350 H,0.165
MLG,SHRD/4 SIDES,MIL PLZ,30 GOLD,SAFETY CONTROLLED (ONE
ON MAIN BOARD, ONE ON FRONT PANEL)
-17 131-5457-00 3
CONN,HDR; PCB,;MALE,STR,1 X 3,0.10 CTR,0.535 H X 0.130
TAIL,SHRD/4 SIDES,CTR PLZ,LATCHING,BD RETENTION,30 GOLD,
-18 174-4771-00 1
CA ASSY,SP; IDC,RIBBON,10.00 L,DOUBLE ENDED,FEMALE,2 X 5
POS;F/P BD TO MAIN BD,SAFETY CONTROLLED
-19 200-4800-00 1
COVER,MINI; 2X FEX-440,SAFETY CONTROLLED
-20 210-0457-00
NUT,PL,ASSEM WA; 6-32 X 0.312,STL CD PL,W/LOCKWASHER
-21 211-0410-00
SCR,ASSEM WSHR; 4-40 X 0.437,PNH,STL,CDPL,T-10 TORX DR
1
Quantity varies with instrument model.
5–6 WVR6020, WVR7020, and WVR7120 Waveform Rasterizers Service Manual
