Telcoma Automations ACE401 User Manual

GB
CHARACTERISTICS AND PARTS DESCRIPTION
ACEseriesgearmotors(2013)are extremelyversatileunitsfortheautomationof slidinggatesupto 800Kg.
This manual covers three models with different powers and gear reducers but the same dimensions and installation
procedure;electricalconnectionsand programming arealsostandardised.
TheECUof eachmodel isprogrammedwith differentparameterstoensure anexcellentpower/sensitivitytoobstaclesratio.In
addition to the encoder control, units have two balanced sensitive edge inputs and a connection for synchronising the
movementoftwoleafs.
1.motorcover
2.magneticlimit switch sensors
3.pinionguard
4.pinion
5.sidecovers
6.ECU
7.ECUsupport
8.12V1.2Ahbattery compartment(ACE401only)
9.motorheight adjustmentstudbolt
10.motorfixingcrews
11.motorreleaselock
12.motorreleaselever
13.230V mainspowerconnectionterminalboard
14.motor
15.bracketswithlimitswitchmagnet
Partsdescription(fig.A)
TECHNICAL DATA
Power supply voltage
Motor voltage
Max. motor current
Max. absorbed power
Protection class
Electronic deceleration
Maximum torque
Max. thrust force
Max. gate speed
Operating temperature
Motor speed control
Duty cycle intensity
Weight
Inputs for 8K2 safety edges
Master/Slave control
230Vac
MOTOR ACE401U.M.
Vdc 24
A 6
W 150
44
YES
Nm
IP
400
5
N
m/min 10
°C
intensive
-20 +55
YES
10
YES
YES
230
ACE601
24
8
250
44
YES
YES
600
10
16
intensive
-20 +55
YES
10
YES
YES
230
ACE801
24
12
300
44
YES
YES
800
15
10
intensive
-20 +55
YES
10
YES
YES
Kg
Max. torque during the starting Nm 10 16 24
Max. gate weight Kg 400 600 800
Encoder
Control unit power supply Vdc
YES
24 ± 10%
YES YES
Magnetic limit switch
Compatible with Sun Power
YES
YES
YES YES
Control unit
Battery compartment
A124A4
12V 1.3Ah (optional)
A124A6
/
A124A8
/
mod.
mod.
35
