Table 14-1. TPS65994QFNEVM Bill of Materials (continued)
Designator QTY Value Description Package Reference Part Number Manufacturer
U5_PA, U5_PB 2 USB Type-C Port Protector: Short-to-VBUS
Overvoltage and IEC ESD Protection, RUK0020B
(WQFN-20)
RUK0020B TPD6S300ARUKR Texas Instruments
U6 1 Tiva C Series Microcontroller, 256 KB Flash, 32 KB
SRAM, 12 Bit, 12 Channels, -40 to 105 degC, 64-Pin
LQFP (PM), Green (RoHS & no Sb/Br), Tape and
Reel
PM0064A TM4C123GH6PMTR Texas Instruments
U7 1 ESD Protection Array for High-Speed Data Interfaces,
2 Channels, -40 to +85 degC, 3-pin SOT (DRT),
Green (RoHS & no Sb/Br)
DRT0003A TPD2E009DRTR Texas Instruments
U8 1 High-Speed USB 2.0 (480 Mbps) 1:2 Multiplexer /
Demultiplexer Switch with Single Enable, 6 ohm
RON, 2.5 to 3.3V, -40 to 85 degC, 10-Pin UQFN
(RSE), Green (RoHS & no Sb/Br)
RSE0010A TS3USB221RSER Texas Instruments
Y1 1 Crystal, 16 MHz, 8pF, SMD 3.2x0.75x2.5mm NX3225GA-16.000M-STD-CRG-1 NDK
C2, C12 0 150pF CAP, CERM, 150 pF, 50 V, ±10%, X7R, 0201 0201 GRM033R71H151KA12D MuRata
FID1, FID2, FID3, FID4,
FID5, FID6
0 Fiducial mark. There is nothing to buy or mount. N/A N/A N/A
R17, R18, R19 0 10.0k RES, 10.0 k, 1%, 0.05 W, 0201 0201 CRCW020110K0FKED Vishay-Dale
R29, R35 0 0 RES, 0, 5%, 0.063 W, AEC-Q200 Grade 0, 0402 0402 CRCW04020000Z0ED Vishay-Dale
R66, R67 0 0 RES, 0, 5%, 0.063 W, 0402 0402 CRCW04020000Z0ED Vishay-Dale
R68, R69, R73, R74,
R76, R105, R106
0 0 RES, 0, 5%, 0.05 W, 0201 0201 CRCW02010000Z0ED Vishay-Dale
R91, R93, R116, R118 0 100k RES, 100 k, 1%, 0.1 W, 0603 0603 CRCW0603100KFKEA Vishay-Dale
TPS65994QFNEVM Bill of Materials www.ti.com
52 TPS65994 EVM User Guide SLVUBM1C – JANUARY 2019 – REVISED JANUARY 2021
Submit Document Feedback
Copyright © 2021 Texas Instruments Incorporated
