Texas Instruments TRIS TMS37122 User Manual

CHAPTER 4
59
Product Specification Data
4.1 Absolute Maximum Ratings
All further Recommended Operation Conditions are valid for the full operating free-air tem-
perature range, unless otherwise noted!
Parameter Sign Note Min Nom Max Unit
Operating free-air
temperature
TaR -40 85 ºC
Storage Temperature Ts -40 100 ºC
Battery Voltage VBAT -0.3 5.5 V
Input Voltage VIN MOD, TX -0.3
1.1 x
VBAT
V
Input Voltage VIN
TEN, TCLK,
TDAT
-0.3
1.1 x
VBAT
V
High Level Output Current IOH
WAKE, CLKA/M
EOBA, TDAT
100 µA
Low Level Output Current IOL
WAKE, CLKA/M
EOBA, TDAT
100 µA
Input Current Iant
RF1, RF2, RF3
See Note 1
10 mA
Note 1:
Continuous activation of one RF input at a time.
