20
5355
Galley
Hot Liquid
Containers
Master Control
Switch
Ice Chest with
Manual Overboard
Drain, and Wine
Storage
Press to turn Galley Hot Liquid
Container Heater On and Off
(Light Designates On)
Master Cabin Control Switch Panel
(Located in Galley Header)
Hot Liquid Container Switch Panel
The master cabin control switch panel located in the galley header controls the hot
liquid containers. Pressing the switch once will turn the hot liquid container heater
on, pressing again will turn heater off.
Caution: Do NOT turn hot liquid container heater on when tank is empty.
Manual Overboard Drain Operation (for Ice Chest)
The ice-chest drawer located in the lower section of the galley is equipped with a
manual drain valve used to empty water from the ice chest. To open drain valve:
1. Open ice-chest drawer.
2. Turn drain valve counter-clockwise
to the open position.
Closed
open
