Hot Liquid Container Removal
Two Prepco hot liquid containers are located in the upper section of the galley. Each
hot liquid container holds one gallon and is easily removed for filling. The master
control switch panel in the galley header controls each hot liquid container separately
(see previous page for switch operation).
To remove and fill hot liquid containers:
1. Lift up on the bottom of the
hot liquid container doors
and rotate up 90 degrees.
2. Slide doors back.
3. Lift up slightly on the front of
the hot liquid containers and
slide forward to remove.
Caution: Be careful when
removing, hot liquid
containers may be HOT.
Remove
Lid to Fill
Manual Drip Tray Drain Operation
Push to Drain
Drip Tray
Caution: Do NOT remove hot liquid container while tank heater is turned on.
