12. Final Checks
Before releasing the lift for use, all of the verifications indicated in the end-installation list found in the user
manual, must be performed. The list of tests found in the user manual must be filled out and signed by the
installer.
TYPE
OF
TEST
PAR.
N.
TEST
RESULT
Positive
Negative
Value
Mechanical and
hydraulic safety
7.1
1
Check correct reclosing of the floor door
7.2.1
2
Verification of the emergency manual descent
-
7.2.2
3
Verification of the parachute valve
-
7.2.4
4
Verification of the calibration of the pressure switch maximum pressure
regulator
-
7.2.5
5
Verification of the mechanical parachute
-
7.2.6
6
Verify the safety anti-crush intervention of the cabin doors (only for versions
OR41/GU41
*
7
Verify suspension elements
-
Electrical safety
7.3
1
Verify the well access intervention control
-
7.3.1
2
Check operation of the locks and door closing contacts of the floor doors
-
7.3.2
3
Verify alarm operation
-
7.3.3
4
Verify the electrical emergency descent in a black-out condition
-
7.3.5
7.3.6
5
Electrical ground insulation test and ground continuity test (indicate the
value)
-
7.3.7
6
Verify overrun
-
7.3.8
7
Verify anti creep levelling/floor levelling
-
7.3.9
8
Verification of the mechanical parachute switch
-
7.3.10
9
Check emergency button in the pit
7.3.11
10
Verify electrical safety intervention in the well strut
-
7.3.12
11
Verify electrical safety intervention in the header strut
-
7.3.13
12
Verify voltage to batteries
Machine operation cycle
7.4.1
1
Interior machine movement commands
-
7.4.2
2
Floor call commands
-
7.4.3
3
“STOP” button activation
-
7.4.4
4
Test at nominal speed with maximum load (see load limit)
-
7.4.4
5
Static test with load equal to load limit multiplied by 1.25
-
7.4.5
6
Verify the free spaces between the well and the platform (indicate maximum
value)
-
-
7.4.5
7
Verify the stopping distance (indicate maximum value)
-
-
7.4.6
8
Verify the intervention of the photocells or the cabin sensitive edge (only for
versions OR04/GU04)
-
7.4.7
9
Verify the safety anti-crush intervention of the cabin doors (only for versions
OR41/GU41
-
7.4.8
10
Verify optical sensor operation (for versions OR42/GU42 only)
**
11
Verify presence of signage
-
**
12
Verify operation of the telephone or intercom/switch-group telephone
**
13
Make sure the door unlock triangular emergency key is present in the
"separate and known" location, reserved for use by educated persons
-
Date Installer Signature / Stamp
____________ _________________________________
