1.26 1.26
Weight and Dimensions
Wheel Base: 1610 mm (63.4˝)
Working Width: 3640 mm (143.3˝)
Cutting Width: 3460 mm (136.2˝)
Transport Width: 1890 mm (74.5˝) at 13mm (1/2˝) height of cut
Overall Length: 2930 mm (115˝)
Overall Height: 1775 mm (70˝) with R.O.P.S folded
2385 mm (94˝) with R.O.P.S in its vertical operating position
Working Weight: Including 2 post R.O.P.S, 8˝ 6 blade cutterheads and full tank of fuel. It
excludes the operator and any other options.
1870 kg (4123 lb)
Recommended Lubricants and Hydraulic Fluids
Grease Points: A good quality medium grease
Engine: Refer to Engine Operators Manual
Hydraulic System:
Ambient Temperature Range
0 - 30 C (32 - 86 F) 15 - 40 C (59 - 104 F)
ISO viscosity grade
46 hydraulic oil
ISO viscosity grade
68 hydraulic oil
Should you be in any doubt please contact your TORO dealer. Using incorrect grades will cause premature wear
of hydraulic components and invalidate warranty.
Cutterhead
MK3 200 mm Cutterhead MK3 254 mm Cutterhead
Cutting Width: 762 mm (30˝) 762 mm (30˝)
Cylinder Diameter: 200 mm (8˝) 254 mm (10˝)
Cylinder Speed: 1050 rpm approx 1050 rpm approx
Height of Cut: 12 mm (0.5˝) to 80 mm (3˝) 12 mm (0.5˝) to 80 mm (3˝)
Number of Blades: 4, 6, 8, 10 4, 6
Smooth Rear Roller: Standard Standard
Smooth Front Roller: Optional -
Grooved Front Roller: Optional -
Conguration: Fixed/Floating Fixed
SPECIFICATIONS
