Toro 04022 Installation Instructions

6
InstallingtheWireHarness
andThrottleCable
Partsneededforthisprocedure:
1Wireharness
1Engineswitch
4
Cableties
1Throttlecable
1
Cableclip
1
Consolecover
Procedure
1.Installthewireharnesstotheinterlockconnector
onthewireharnessbracketandclipthewire
harnesstothebracket(Figure13).
g274613
Figure13
1.Wireharnessconnectors3.Interlockconnector
2.Installthewireharness
cliphere.
2.Mountthegreengroundwireusingthecowling
boltunderthefueltank,andconnecttheredwire
totheengineconnectorasshowninFigure14.
Note:Applyskin-overgreasetotheboltand
groundlugterminal.
g274609
Figure14
1.Cowlingbolt
4.Engineconnector
2.Groundwire
5.Installthiswireharness
connectortotheengine
connector.
3.Disconnectthiswirefrom
theengineconnector.
3.Routetheharnessuptheleftsideofthehandle
(Figure15).
4.Installtheengineswitchintheconsoleand
connectittothewireharness(Figure15).
Note:Connectthewireharnesstothe
hourmeter(ifequipped).
5.Securethewireharnessundertheconsole
coverwithasnapclipandcabletiesasneeded.
6.Ifthemachinehasalightkit,usethewire
harnessadaptertoinstallthemainwireharness
totheengine.
7.Attachthecablesandwireharnesstothe
handlesusingthe4newcable-ties(Figure15).
11
