InstallingtheTransport
Wheels
Optional
Partsneededforthisprocedure:
2Transportwheel
Procedure
1.Pushthekickstanddownwithyourfootandpull
uponthehandletosupportthemachineonthe
kickstand.
2.Slideawheelontoanaxle.
3.Pivotthewheellockingclipawayfromcenter
ofthewheel,allowingittoslidefartherontothe
axle(Figure10).
g017591
Figure10
1.Lockingclip
4.Rotatethewheelbackandforthuntilitslides
completelyontotheaxleandthelockingclipis
securedinthegrooveontheaxleshaft.
5.Repeattheprocedureontheoppositesideof
themachine.
6.Inatethetiresto83to103kPa(12to15psi).
7.Carefullylowerthemachineoffthekickstand.
5
AdjustingtheCuttingUnit
NoPartsRequired
Procedure
Beforeoperatingthemachine,completethefollowing
adjustments:
•LevelingtheRearDrumtotheReel(page36)
•AdjustingtheBedknifetotheReel(page36)
•AdjustingtheHeight-of-Cut(page37)
•AdjustingtheGrassShieldHeight(page38)
•AdjustingtheCut-OffBar(page39)
6
InstallingtheCEDecals
Partsneededforthisprocedure:
1Production-yeardecal
1
CE-markdecal
Procedure
Ifyouusethismachineinacountrythatcomplies
toCEstandards,applytheproduction-yeardecal
andtheCE-markdecalneartheserialplate;referto
Figure11.
g235301
Figure11
1.Production-yeardecal
3.CE-markdecal
2.Serialplate
