4.Tightenthejamnutsuntiltheoutsidethrust
washersjustrotatefreely.
5.Tightenthespring-tensionnutuntilthespringis
collapsed,thenbackitoff1/2turn.
6.Adjustthebedbar;refertoAdjustingthe
BedknifetotheReel(page36).
BacklappingtheReel
1.Removetheplugintherightreel-drivecover
(Figure63).
g007633
Figure63
1.Coverplug
2.Inserta1/2inch-driveextensionbar,connected
tothebacklappingmachine,intothesquarehole
inthecenterofthereelpulley.
3.BacklapaccordingtotheprocedureintheT oro
SharpeningReelandRotaryMowersManual,
Form80-300PT .
DANGER
Contactwiththereelorothermoving
partscanresultinpersonalinjury.
•Stayawayfromthereelwhile
backlapping.
•Donotuseashort-handledpaint
brushforbacklapping.PartNo.
29-9100Handleassembly,completeor
asindividualparts,areavailablefrom
yourlocalauthorizedTorodistributor.
Note:Forabettercuttingedge,runale
acrossthefrontfaceofthebedknifewhenthe
lappingoperationiscompleted.Thisremoves
anyburrsorroughedgesthatmayhavebuilt
uponthecuttingedge.
4.Installthepluginthecoverwhenyoucomplete
thisprocedure.
40
