•ENGINERPM/STATUS—indicatestheenginerpm.
•FAULTLOG—indicatesthatthereisacurrentfault
logtoreview.
•GENERATORVOLTAGE/STATUS—indicatesthe
generatorvoltage.
•HOURMETER—indicatesthetotalhoursthe
machinehasoperated.Itstartstofunction
wheneverthekeyswitchisrotatedtoOn.
•PTOSPEED—indicatesthePTOspeed.
•BATTERYVOLTAGE—indicatesthebatterypotential
inVolts.
•COOLANTTEMPERATURE—indicatestheengine
coolanttemperatureineither°Cor°F.
•FUNCTIONALCONTROLSTATUS—transportmodeis
indicatedbyarabbitandmowmodeisindicated
byaturtle.
•ENGINEOILPRESSURElight—thisiconappearsif
theengineoilpressuredropsbelowasafelevel.
•MENUACCESS/BACKbutton—pressthisbuttonto
accesstheInfoCentermenus.Youcanuseitto
backoutofanymenuyouarecurrentlyusing.
•DOWNbutton—usethisbuttontoscrolldown
menus.
•RIGHTbutton—usethisbuttontoopenamenu
wherearightarrowindicatesadditionalcontent.
Note:Thepurposeofeachbuttonmaychange
dependingonwhatisrequiredatthetime.Each
buttonwillbelabeledwithanicondisplayingits
currentfunction.
UsingtheMenus
ToaccesstheInfoCenter-menusystem,pressthe
MENUACCESSbuttonwhileatthemainscreen.This
bringsyoutotheMAINMENU.Refertothefollowing
tablesforasynopsisoftheoptionsavailablefrom
themenus:
MAINMENU
MenuItemDescription
FAULTSTheFAULTSmenucontains
alistoftherecentmachine
faults.RefertotheService
ManualoryourAuthorized
ToroDistributorformore
informationontheFAULTS
menuandtheinformation
containedthere.
SERVICETheSERVICEmenucontains
informationonthemachine
suchashoursofuseandother
similarnumbers.
DIAGNOSTICSTheDIAGNOSTICSmenu
listsvariousstatesthatthe
machinecurrentlyhas.Y ou
canusethistotroubleshoot
certainissuesasitwillquickly
tellyouwhichmachine
controlsareonandwhichare
off.
SETTINGSTheSETTINGSmenuallows
youtocustomizeandmodify
congurationvariablesonthe
InfoCenterdisplay.
ABOUTTheABOUTmenuliststhe
modelnumber,serialnumber,
andsoftwareversionofyour
machine.
SERVICE
MenuItemDescription
HOURS
Liststhetotalnumberofhours
thatthemachine,engine,
reels,backlap,andfanhave
beenon,aswellasthe
numberofhoursthemachine
hasbeentransportedand
overheated.
COUNTSListsthenumberofpreheats
andstartsthemachinehas
experienced.
BACKLAP
TurnsbacklappingON/OFF
(onceONyoucanturn
backlappingOffwiththis
settingorbyturningoffthe
ignitionkey).
DIAGNOSTICS
MenuItemDescription
ENGINERUN
Indicatesifthefollowingitems
areactive:Keystart,keyrun,
joysticklower,joystickraise,
neutral,seatorparkingbrake,
OKrun,andRTRorETR.
S1–S4Controlstheraisingand
loweringofthesolenoids.
REELSENABLE
IndicatesiftheeReelis
enabled.
SETTINGS
MenuItemDescription
UNITS
Controlstheunitsusedonthe
InfoCenter.Themenuchoices
areEnglishormetric.
LANGUAGE
Controlsthelanguageused
ontheInfoCenter.
LCDBACKLIGHTControlsthebrightnessofthe
LCDdisplay.
LCDCONTRASTControlsthecontrastofthe
LCDdisplay.
19
