3.Hookthescrewheadontothecuttingedgeofthe
bedknifeandresttherearendofthebarontothe
rearoftheroller(Figure17).
Figure17
1.Gaugebar
4.Rotatetheadjustingscrewuntiltherollercontacts
thefrontofthegaugebar.Adjustbothendsofthe
rolleruntiltheentirerollerisparalleltothebedknife.
Important:Whensetproperly,therearand
frontrollerswillcontactthegaugebarandthe
screwwillbesnugagainstthebedknife.This
ensuresthattheheight-of-cutisidenticalatboth
endsofthebedknife.
5.Tightenthenutstosecuretheadjustment.Donot
overtightenthenut.Tightenenoughtoremoveplay
fromthewasher.
Note:Usethefollowingcharttodeterminewhich
bedknifeisbestsuitedforthedesiredheightofcut.
RecommendedBedknife/HeightofCutChart
Bedknife
Part
Number
HeightofCut
Micro-cut(Optional)
93-4262
.062-.188inch(1.5-4.7mm)
ExtendedMicro-cut
(Optional)
108-4303
.062-.188inch(1.5-4.7mm)
EdgeMaxMicro-cut
(Optional)
115-1880
.062-.188inch(1.5-4.7mm)
Tournament
(Standard)
93-4263
.125-.500inch(3.1-12.7
mm)
ExtendedT ournament
(Optional)
108-4302
.125-.500inch(3.1-12.7
mm)
EdgeMaxT ournament
(Optional)
115-1881
.125-.500inch(3.1-12.7
mm)
Low-cut(Optional)
93-4264
.188-1.00inch(4.7-25.4
mm)
RecommendedBedknife/HeightofCutChart(cont'd.)
High-cut(Optional)
94-6392
.312-1.00inch(7.9-25.4
mm)
Fairway(Optional)
63-8600
.375-1.00inch(9.5-25.4
mm)
8
AdjustingtheCut-OffBar
NoPartsRequired
Procedure
Adjustthecut-offbartoassuretheclippingsarecleanly
dischargedfromthereelarea:
1.Loosenthescrewssecuringthetopbar(
Figure18)
tothecuttingunit.
Figure18
1.Cut-offbar
2.Inserta.060inchfeelergaugebetweenthetopof
thereelandthebarandtightenthescrews.Ensure
thebarandreelareequaldistanceapartacrossthe
completereel.
Note:Thebarisadjustabletocompensatefor
changesinturfconditions.Thebarshouldbe
adjustedclosertothereelwhentheturfisextremely
dry.Bycontrast,adjustthebarfurtherawayfrom
thereelwhentheturfconditionsarewet.Thebar
shouldbeparalleltothereeltoensureoptimum
performanceandshouldbeadjustedwheneverthe
reelissharpenedonareelgrinder.
9
