Fuel Gauge (Fig. 20)—Shows amount of fuel in tank.
Operates only when ignition switch is in “ON”
position.
Steering Wheel (Fig. 20)—Turns vehicle. If engine
stalls or power assist fails due to a malfunction,
vehicle steering will require greater effort.
Passenger Hand Hold (Fig. 21)—On dashboard.
Figure 21
1. Passenger hand hold
2. Tachometer (Optional)
Tachometer—Optional (Fig. 21)—Indicates engine
RPM. Gear selection graphics indicates speed.
Remote Hydraulic Lever (optional-not shown)—
Controls hydraulic flow to optional quick rear
couplers.
1
2
23
