Toro 07205 User Manual

Figure 48
1. Hydraulic Reservoir
2. Drain plug
Replacing Hydraulic Filter
(Fig. 49)
Use the Toro replacement filter (Part No. 54-0110).
Use of any other filter may void the
warranty on some components.
1. Position vehicle on a level surface, stop engine,
engage parking brake and remove key from
ignition switch.
2. Clean area around filter mounting area. Place
drain pan under filter and remove filter.
Figure 49
1. Hydraulic Filter
2. Gasket
3. Lubricate new filter gasket.
4. Assure filter mounting area is clean. Screw filter
on until gasket contacts mounting plate. Then
tighten filter one-half turn.
5. Start engine and let run for about two minutes to
purge air from the system. Stop the engine and
check the hydraulic oil level and for leaks.
Change Front Differential Oil
Front-Wheel Drive Models Only (Fig. 50)
Change front differential oil every 800 hours.
1. Position vehicle on a level surface, stop engine,
engage parking brake and remove key from
ignition switch.
2. Clean area around drain plug on side of
differential. Place drain pan under drain plug.
Figure 50
1. Front differential
2. Fill/check plug
3. Drain plug
3. Remove drain plug and let oil flow into drain pan.
Reinstall and tighten plug when oil stops
draining.
4. Clean area around fill/check plug on side of
differential.
5. Remove fill/check plug and add 10W30 oil until
oil is up to hole.
6. Re-install fill/check plug.
1
2
Important
1
2
44
